Series CONDUCTOR-DIELECTRIC-(SHIELD 1,2,3)-JACKET NOTE Total: 29
141F (50Ω) 0.945-2.96-(3.54) 1
141F (75Ω) 0.54-3.04-(3.53) 1
141FJ (50Ω) 0.94-3.02-(3.56)-4.58 =MSF-358T-Cu-PE 0.92-2.9-3.5-4.5 2
141MF (50Ω) = SS402 0.94-2.97-(3.18-3.48)-4.01 1
141MFU(50Ω) 1-2.97-(3.25-3.58)-4.6mm ■URETHANE Jacket ~18GHz, flexible: very good 1
141TP (50Ω) 0.92-2.98-(3.58) =MCT-358T 1
250F (50Ω) 1.63-5.31-(6.3) =FLEXFORM 401L 1.88-5.31-6.35 1
250FJ (50Ω) 1.63-5.31-(6.3)-7.1 3
250TP (50Ω) 1.65-5.31-(6.35) =MCT-635T 1
34TP (50Ω) 0.2-0.66-0.86 1
47F (50Ω) 0.27-0.94-(1.19) 1
47FJ (50Ω) 0.27-0.94-(1.19)-2.78 1
47TP (50Ω) 0.29-0.92-(1.19) 1
63F (50Ω) 0.41-1.3-1.7mm 1
85F (50Ω) 0.53-1.68-(2.15) 1
85F (75Ω) SEMIRIGID FLEXIBLE 0.28-1.65-2.18 1
85FJ (50Ω) 0.51-1.67-(2.15)-2.65 2
85FJ (75Ω) SEMIRIGID FLEXIBLE JACKET 0.28-1.65-2.18-2.78 1
85MF (50Ω) = SS405 0.511-1.64-(0.05/5-2.18)-2.64 1
85TP (50Ω) 0.51-1.68-(2.2) 1
EXLH-21R (50Ω) 1.4-4.05-(4.25-4.65)-5.35 1
MUA165SD (50Ω) 0.94-*-(*,*)-4.2mm ~45GHz, 4.2Φ, COLOR/BLUE 1
MUAF05SD (50Ω) 0.73-2.15-(2.33-2.68)-3.18mm ~55GHz, 3.18Φ, COLOR/BLUE 1
SUCOFORM 141 (50Ω) Suhner 0.95-2.95-(3.58)-4.6mm Lab TEST CABLE 1
