| Series |
CONDUCTOR-DIELECTRIC-(SHIELD 1,2,3)-JACKET |
NOTE |
Total: 68
|
|
|
1.5C-2V (75Ω)
|
0.26-1.6-(1ST)-2.9 |
|
1
|
|
|
1.5D-2V (50Ω)
|
0.54-1.6-2.1-2.95 |
|
2
|
|
|
1.5D-EXHW
|
0.54-1.60-(1.98-2.35)-3.4 |
TA-PE-(TA-TA)-HFPE |
1
|
|
|
1.5D-HQEW (50Ω)
|
0.54-1.6-(*-2.6)-3 FUJIKURA |
PHONE TEST CABLE |
1
|
|
|
1.5DHQ (50Ω)
|
0.54-1.6-(**)-3mm |
|
1
|
|
|
1.5DS-QEHB
|
0.18-1.6-0.1/5.16-3 |
Copper-XLPE-AL Tape-TC-CPVC |
1
|
|
|
EM-1.5D-HQEW (50Ω)
|
0.54-1.6-(**)-3.4±0.3mm |
PHONE TEST CABLE |
1
|
|
|
MC CABLE 1.13Ø(#59) (50Ω)
|
0.24-0.68-(0.93)-1.13 |
|
3
|
|
|
MC CABLE 1.24Ø(#56) (50Ω)
|
0.26-0.8-(1.05)-1.24 |
|
1
|
|
|
MC CABLE 1.32Φ
|
0.24-0.7-(0.9)-1.32 |
■shenyucable |
1
|
|
|
MC CABLE 1.33Ø(#54) (50Ω)
|
0.305-0.88-(1.13)-1.33 |
|
1
|
|
|
MC CABLE 1.37Ø (50Ω)
|
0.306-0.9-(1.13)-1.37mm |
MOBILE, PHONE TEST |
1
|
|
|
MC CABLE 1.48Φ(#51)
|
0.305-0.84-(1.24)-1.48mm |
MOBILE, PHONE TEST |
1
|
|
|
MC CABLE 1.48Φ (HITACHI 1X30AWG)
|
0.3-0.84-(*)-1.48mm |
MOBILE, PHONE TEST |
1
|
|
|
3C-2VS (75Ω)
|
0.54-3.1-(1ST)-5.4 |
|
1
|
|
|
3D-FV (50Ω)
|
1.15-3.3-(1ST-2ST)-5.3 |
|
1
|
|
|
5C-2VS (75Ω)
|
CCTV, HD-SDI |
|
1
|
|
|
7C-HFB (75Ω)
|
1.8-7.3-(8.3)-10.2 |
|
1
|
|
|
DACAR 037-6
|
1.11-2.95-3.57-4.9 |
BC-FOAM_PP-(AL TAPE-Tinned copper)-TPE-U |
1
|
|
|
DACAR 417 (50Ω) LEONI
|
0.295-0.95-(1.4)-1.7 |
CAR ANT CABLE |
1
|
|
|
DACAR302 Double shield
|
0.81-2.15-(2.25-2.65-3.05)-3.7 |
CAR 발포 케이블 ~6GHz, V2X |
1
|
|
|
DACAR302 single shield
|
0.76-2.05(2.2-2.6)-3.3 |
CAR 발포 케이블 ~6GHz, V2X |
2
|
|
|
L-200(50Ω)
|
1.17-3.4-(3.6T-4.2T)-5.3 |
■편조에 납땜/가능 |
1
|
|
|
LMR195 (50Ω)
|
0.94-2.79-(2.95-3.53)-4.95 |
|
1
|
|
|
LMR200 (50Ω)
|
RG CABLE 1.16-3.20-3.07-3.65-5.2 |
|
2
|
|
|
LMR240 (50Ω)
|
1.42-3.81-(3.94-4.52)-6.1 |
|
3
|
|
|
LMR240_UF(50Ω)
|
1.42-3.81-(3.94-4.52)-6.1 |
ULTRA FLEXIBLE |
1
|
|
|
LMR300 (50Ω)
|
R1.77-4.82-(4.97-5.71)-7.62 |
|
1
|
|
|
LMR400 (50Ω)
|
2.74-7.24-(7.39-8.13)-10.29 |
|
1
|
|
|
LMR400-FR(50Ω)
|
2.74-7.24-(7.39-8.13)-10.29 |
RISER CMR, 난연케이블 |
1
|
|
|
LMR400-UF (50Ω) Times
|
2.74-7.24-(7.39-8.13)-10.29 |
|
1
|
|
|
LMR600 (50Ω)
|
RG CABLE |
|
1
|
|
|
RF-MF50141
|
|
|
1
|
|
|
RG11 (75Ω)
|
2.74-7.24-(7.95)-10.3 BLACK |
|
3
|
|
|
RG142 (50Ω)
|
0.95-2.95-(3.60-4.23)-4.95 |
|
1
|
|
|
RG174 (50Ω)
|
0.48-1.52-1.95-2.8 BLACK |
|
1
|
|
|
RG178 (50Ω)
|
0.3-0.83-(1.3)-1.8 BRWON |
|
1
|
|
|
RG179 (75Ω)
|
0.57-1.6-(2.06)-2.54 |
|
1
|
|
|
RG179DS (75Ω)
|
0.31-1.6-(2.0-2.5)-3.0 |
|
1
|
|
|
RG213 (50Ω)
|
2.26-7.24-(7.95)-10.3 |
|
1
|
|
|
RG214 (50Ω)
|
2.25-7.25-(8.05-8.75)-10.79 Poemium, Economy Type |
|
2
|
|
|
RG223 (50Ω)
|
0.89-2.95-(3.84-3.90)-5.38 |
|
1
|
|
|
RG316 (50Ω)
|
0.51-1.52-(2.0)-2.5 |
|
2
|
|
|
RG316DS (50Ω)
|
0.54-1.54-(2.05-2.50)-3.05 |
|
1
|
|
|
RG393 (50Ω)
|
2.4-7.24-(8-8.75)-9.9 |
|
1
|
|
|
RG400 (50Ω)
|
1.03-2.95-(3.6-4.2)-4.95 |
|
1
|
|
|
RG58 (50Ω)
|
0.9-2.95-(3.6)-4.95 |
|
1
|
|
|
RG58_L/L (50Ω)
|
2.256-2.95-(*)-4.95mm |
|
2
|
|
|
RG59 (75Ω)
|
0.58-3.6-(4.4)-6.1 |
|
1
|
|
|
RG6 (75Ω)
|
1.05-4.57-(4.7-5.3)-7.06 |
|
1
|
|
|
RG8/U (50Ω)
|
2.74-7.25-(t0.15*24*7)-10.16 |
|
1
|
|
|
RG8/U 9913 (50Ω)
|
2.74-7.25-(*)-10.3 |
|
1
|
|
|
SIFS 1C (50Ω) = FLS-98N (50Ω)
|
0.4-1.47-(1.53-1.89)-2.4 |
|
2
|
|
|
SIFS 3C (50Ω)
|
0.4-1.47-(1.53-1.89)-2.4±0.05mm |
시설/설치용 |
1
|
|
|
SIFS 4C (50Ω)
|
0.4-1.47-(1.53-1.89)-2.4±0.05mm |
시설/설치용 |
1
|
|
|
